The research group in Electronics Engineering Applied to Intelligent Spaces and Transport (GEINTRA) of the Department of Electronics of the University of Alcalá has developed a sensor device and its corresponding procedure to detect the presence of any type of objects (vehicles, people, animals, etc…) in points of interest of the railway route (level crossings, tunnels, etc.), sending to the train the visual information and corresponding warning signs.
The device consists of a set of cameras located in the environment of each point of interest, an infrared lighting system, an image processing module and a wireless communication system with the train.
The system contributes to the increase of safety in rail transport, providing the machinists with visual information about the state of the conflicting points and notifying the presence of obstacles. The system is capable of detecting the presence of objects in daylight and nighttime conditions.
The group seeks for licensing agreements, technical cooperation agreements or commercial agreements with technical assistance, with companies that work in the manufacture of safety equipment for rail transport systems.
The invention relates to a sensor and communication system that allows the driver to have visual information about the conflicting point.
Its main function is to supervise critical points within the railway line (level crossings, people transit areas, entrance / exit of tunnels, etc.) where the presence of objects, people, animals, etc., can be a danger for themselves and for the trains in circulation.
For this purpose, video cameras with characteristics that allow day / night vision will be used, together with a system of illumination in infrared wavelengths, which allows obtaining visual information (both day and night) of the area to be monitored, an image processing system to detect the presence of obstacles (in changing circumstances of weather conditions, changes in lighting, presence of shadows, etc.), and activate the infrared lighting system when the environmental lighting requires it. The captured images will be sent via radio to the train, along with the information that, by means of an image display system on board the train, warns the driver, with an alarm, of the presence of objects in the area to be monitored.
The use of four cameras, two day-vision cameras (color cameras) and two night-vision cameras (monochromes), allows, together with the infrared illumination spotlights, to obtain precise visual information of the area to be monitored, and guarantee the detection of obstacles in diurnal and nocturnal conditions, even in extreme conditions of environmental lighting and with the presence of shadows caused by the weather conditions and possible elements present in the environment of the area to be monitored (poles, trees, etc.). Besides, due to European safety regulations in the railway structure, it cannot be illuminated in the visible spectrum, since it may tend to be confused with the road signaling system.
INNOVATIVE ASPECTS
- The system includes an intelligent video processing module, whose mission is the automatic detection of possible elements that can cause an accident (with danger for the personnel on the ground, like a run over, and also with danger for the train, like a derailment).
- In addition, the image processing system allows image transmission from the risk area to the train approaching the area and the detection of anomalous objects in that area and the transmission of the corresponding alarm to the train.
COMPETITIVE ADVANTAGES
The proposed invention has the following advantages:
- Images in real time, and continuously, of what is happening at a specific point.
- Quick assessment of whether there is a risk situation.
- Increased safety in circulation.
- Elimination of possible human errors and facilitates the function of the machinist.
High commercial potential at national and international level with moderate cost.
PATENT GRANTED
Patent granted on February 2013, with publication number ES2377802
Current development status
Finished technologies
Desired business relationship
Technology selling
Patent licensing
Technology development
The group seeks to reach license agreements, technical cooperation agreements or commercial agreements with technical assistance, with companies working in the manufacture of safety equipment for rail transport systems.
